The ACES line of portable batteries are optimized for small boats that are used for recreation.



The batteries have an extremely low weight and a very high capacity and can be transported easily. The weight is about 6 times lower compared to lead-acid batteries. Because of the high capacity and low weight the batteries can be used for 3-8 hours, depending on the speed.

AL22V60HN

AL22V60HN

Energy
1300 Wh
Capacity
60 Ah
Voltage
24 V (range 19V - 25.2V)
Weight
8 kg
Charge cycles
600 - 1000
Dimensions
270×240×185 mm
Case
Glass fiber reinforced resin
Grips
One hand grip
Connections
SB50 Anderson
Water resistance
IP65
Indicators
Voltmeter, USB and switch

AL24V120HN

AL24V120HN

Energy
3000 Wh
Capacity
120 Ah
Voltage
24 V (range 21V - 29.4V)
Weight
18 kg
Charge cycles
600 - 1000
Dimensions
280×190×260 mm
Case
Glass fiber reinforced resin
Grips
One hand grip
Connections
M10 screw connection
Water resistance
IP65
Indicators
Voltmeter that displays voltage at button press

AL12V50HF

AL12V50HF

Energy
640 Wh
Capacity
50 Ah
Voltage
12.8 V (range 10V - 14.4V)
Weight
7 kg
Charge cycles
3000
Dimensions
270×240×185 mm
Case
Reinforced resin
Grips
one handgrip
Connections
SB50 Anderson
Water resistance
IP65
Indicators
Voltmeter, USB and switch

AL12V80HF

AL12V80HF

Energy
1024 Wh
Capacity
80 Ah
Voltage
12.8 V (range 10V - 14.6V)
Weight
8.5 kg
Charge cycles
3000
Dimensions
270×240×185 mm
Case
Reinforced resin
Grips
one handgrip
Connections
Anderson SB50
Water resistance
IP65
Indicators
Voltmeter, USB and switch
